PLC Starter Kit Programmable Controller, Software Ladder Developer Programming
Supplied: 1 Migro FX Board Controller 20 i/o; 12 DC Inputs, 8 Relay Outputs 1 USB Interface Programming Cable 1 Plug In Power Supply 24V input 120/240VAC USB Drive with Ladder Logic Software And BONUS Professional Training Course The basic ladder logic Programming software Software for Windows 10, 32bit. Software is FREE, cost include procurement, examples and data compilation BONUS a training course in ladder logic, from the basic functions to advanced applications as used in the industry today. 1 - PLC Ladder Logic GX Developer Programming Software GX-DEV FX- 8.25 Open Software includes Programming and Hardware Manual Features: 1000 steps Ladder Diagram, and Instruction List Software supports all this FX processors FX0/FX0S, FX0N, FX1S, FX1N, FX(FX2/FX2C) FX2N/FX2NC. FX3u FX MELSEC single user FX Win Version 8.25, 1000 step for FX PLCs controllers series. This is the standard software easy to use and simple, intuitive interface and a short learning curve. Full upload and download, monitor, test and program all the Mitsubishi FX-series PLC package includes CD with the software and manuals in electronic format for programming and hardware installation . 2 - Hardware Features: FX1N-20mr PLC with 12 Inputs and 8 Relay OutputsThis programmable logic controller uses industrial-grade 32-bit MCU with strong anti-interference and faster speed.High quality chip, stable performance, on-line download, on-line monitoring, automatic save when power off.Program is written in ladder logic programming language, supports for GX-Developer, GX-work2.Programming port is the port for program upload, download, test and monitor.It is reusable, stable, easy to learn. The PLC transmission baud rate is 9600. Specifications: Model: FX1N-20mr Operating Voltage: DC24（V） Wide Power Supply Voltage: 10-28VDC Baud Rate: 9600 Programming Software: for GX-Developer, for GX-work2. Size: Approx. 86 x 73 x 20mm / 3.4 x 2.9 x 0.7inch Weight: 120G Module function: This module is programmable control, can achieve thousands of functions, stable and reliable working performance, built-in watchdog timer circuit, to ensure that the module for a long time to run!!! Some of the common features are shown as follows: Turn on the power supply, the relay 1 is closed for N seconds and then disconnect the relay 2 for N seconds.When the power supply is turned on, the relay 1 is switched off after N seconds, and then the relay 2 is closed for N seconds and then is turned off.The power supply is switched on, the relay 1, 2 have no action, when a signal or trigger button, relay 1 closed off after N seconds; then relay 2 closed off after N seconds, until the next trigger, repeat the same action.Through the signal 1, 2 programming, the control can be achieved on the relay 1 and 2 arbitrarily.When the signal 1 has a signal, the relay 1 is closed, the relay 2 is disconnected; when the signal 2 has a signal, the relay 1 is turned off, and the relay 2 is closed.Can be connected to the NPN sensor signal, the sensor signal programming, to achieve arbitrary control of the relay.When the signal 1 is triggered, the relay 1 is controlled, and when the signal 2 is triggered, the relay 2 is controlled.Turn on the power supply, the control motor is turning N seconds, and then reverse N seconds, followed by the cycle.When the signal 1 has a signal, the motor is controlled to rotate; when the signal 2 has a signal, the motor is reversed. These are just some examples, modules can achieve far more than these functions Input high speed pulse C235, C251 and FX1N compatible.Output relay 1A output, Rated current 5A, can directly drive DC solenoid valve, AC solenoid valve, AC contactor, AC motor, etc,. Precautions for use: The PLC with two programming port. The 232 interface, you can directly use the USB-232 serial port with a computer to download the program directly. The TTL interface.Built-in Analog input AD, corresponding to internal data register D5030.(Not D8030)Built-in Analog output DA, corresponding to internal data register D5101.When the PLC need to connect with the touch screen or text, can be used to connect 232 programming port. Assistant Relay Normal Use M0 - M383 Hold After Power Off M384-M1535 Special Use M8000-M8255 State Holding Use S0-S999 Timer 100MS T0-T199 10MS T200-T245 1MS T246-T249 100MS accumulation T250-T255 Counter 16-bit C0-C15(0-32767) 16-bit(Hold After Power Off) C16-C199 High Speed(Hold After Power Off) C200-C255 Data Register 16-bit D0-D127 16-bit(Hold After Power Off) D128-D5029 16-bit Special Use(AD) D5030(Output Voltage: 0-10V) 16-bit Special Use(DA) D5101(Output Voltage: 0-3.3V) Software is Open Version, Free Cost is the compilation and practical example programs Mitsubishi PLC, GX-Developer, GX-work2. are a registered trade marks of Mitsubishi Electric Windows is registered trade mark of Microsoft Corporation Copyright 2023
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Refund Will Be Given As | Money Back |
| MPN | migrogx |
| Format | USB |
| For Operating Systems | Windows |
| Minimum Hard Drive Space | 100 MB |
| Country/Region Of Manufacture | United States |
| Minimum RAM | 2 GB |
| Minimum Processor Speed | 66 MHz |
| Model | GX-DEV |
| Language | English |
| License Category | Lifetime |
| Brand | ELECTRODEPOT |
| Type | Compilers |
Supplied: 1 Migro FX Board Controller 20 i/o; 12 DC Inputs, 8 Relay Outputs 1 USB Interface Programming Cable 1 Plug In Power Supply 24V input 120/240VAC USB Drive with Ladder Logic Software And BONUS Professional Training Course The basic ladder logic Programming software Software for Windows 10, 32bit. Software is FREE, cost include procurement, examples and data compilation BONUS a training course in ladder logic, from the basic functions to advanced applications as used in the industry today. 1 – PLC Ladder Logic GX Developer Programming Software GX-DEV FX- 8.25 Open Software includes Programming and Hardware Manual Features: 1000 steps Ladder Diagram, and Instruction List Software supports all this FX processors FX0/FX0S, FX0N, FX1S, FX1N, FX(FX2/FX2C) FX2N/FX2NC. FX3u FX MELSEC single user FX Win Version 8.25, 1000 step for FX PLCs controllers series. This is the standard software easy to use and simple, intuitive interface and a short learning curve. Full upload and download, monitor, test and program all the Mitsubishi FX-series PLC package includes CD with the software and manuals in electronic format for programming and hardware installation . 2 – Hardware Features: FX1N-20mr PLC with 12 Inputs and 8 Relay OutputsThis programmable logic controller uses industrial-grade 32-bit MCU with strong anti-interference and faster speed.High quality chip, stable performance, on-line download, on-line monitoring, automatic save when power off.Program is written in ladder logic programming language, supports for GX-Developer, GX-work2.Programming port is the port for program upload, download, test and monitor.It is reusable, stable, easy to learn. The PLC transmission baud rate is 9600. Specifications: Model: FX1N-20mr Operating Voltage: DC24（V） Wide Power Supply Voltage: 10-28VDC Baud Rate: 9600 Programming Software: for GX-Developer, for GX-work2. Size: Approx. 86 x 73 x 20mm / 3.4 x 2.9 x 0.7inch Weight: 120G Module function: This module is programmable control, can achieve thousands of functions, stable and reliable working performance, built-in watchdog timer circuit, to ensure that the module for a long time to run!!! Some of the common features are shown as follows: Turn on the power supply, the relay 1 is closed for N seconds and then disconnect the relay 2 for N seconds.When the power supply is turned on, the relay 1 is switched off after N seconds, and then the relay 2 is closed for N seconds and then is turned off.The power supply is switched on, the relay 1, 2 have no action, when a signal or trigger button, relay 1 closed off after N seconds; then relay 2 closed off after N seconds, until the next trigger, repeat the same action.Through the signal 1, 2 programming, the control can be achieved on the relay 1 and 2 arbitrarily.When the signal 1 has a signal, the relay 1 is closed, the relay 2 is disconnected; when the signal 2 has a signal, the relay 1 is turned off, and the relay 2 is closed.Can be connected to the NPN sensor signal, the sensor signal programming, to achieve arbitrary control of the relay.When the signal 1 is triggered, the relay 1 is controlled, and when the signal 2 is triggered, the relay 2 is controlled.Turn on the power supply, the control motor is turning N seconds, and then reverse N seconds, followed by the cycle.When the signal 1 has a signal, the motor is controlled to rotate; when the signal 2 has a signal, the motor is reversed. These are just some examples, modules can achieve far more than these functions Input high speed pulse C235, C251 and FX1N compatible.Output relay 1A output, Rated current 5A, can directly drive DC solenoid valve, AC solenoid valve, AC contactor, AC motor, etc,. Precautions for use: The PLC with two programming port. The 232 interface, you can directly use the USB-232 serial port with a computer to download the program directly. The TTL interface.Built-in Analog input AD, corresponding to internal data register D5030.(Not D8030)Built-in Analog output DA, corresponding to internal data register D5101.When the PLC need to connect with the touch screen or text, can be used to connect 232 programming port. Assistant Relay Normal Use M0 – M383 Hold After Power Off M384-M1535 Special Use M8000-M8255 State Holding Use S0-S999 Timer 100MS T0-T199 10MS T200-T245 1MS T246-T249 100MS accumulation T250-T255 Counter 16-bit C0-C15(0-32767) 16-bit(Hold After Power Off) C16-C199 High Speed(Hold After Power Off) C200-C255 Data Register 16-bit D0-D127 16-bit(Hold After Power Off) D128-D5029 16-bit Special Use(AD) D5030(Output Voltage: 0-10V) 16-bit Special Use(DA) D5101(Output Voltage: 0-3.3V) Software is Open Version, Free Cost is the compilation and practical example programs Mitsubishi PLC, GX-Developer, GX-work2. are a registered trade marks of Mitsubishi Electric Windows is registered trade mark of Microsoft Corporation Copyright 2023
